Message
ID
Message Text Explanation
information to be collected
(decimal number)
Action
Delete the coding of the
root directory from the
specified file. The
displayed directory will be
ignored and the DLMgetras
utility for collecting HDLM
error information will
continue. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL10011-
W
More than one file or directory has been
specified on one line. Line = aa...aa,
Value = bb...bb
Details
Two or more file names or
directory names exist in
the file for defining the
information to be collected.
aa...aa: Line number of
the file for defining
information to be collected
(decimal number)
bb...bb: Indicated contents
in a line
Action
After the DLMgetras utility
for collecting HDLM error
information terminates,
check the contents of the
file for defining the
information to be collected.
This file is shown in the
message. If the contents of
the file are incorrect,
correct them and then try
to collect error information
again. The DLMgetras
utility for collecting HDLM
error information will
ignore the specified file or
directory and continue
processing. For details on
the DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL10012-
W
The specified file or directory does not
exist. Line = aa...aa, Value = bb...bb
Details
The specified file or
directory does not exist in
the file for defining the
8-90
Messages
Hitachi Dynamic Link Manager (for AIX) User Guide
