change the status to the Online(D) status, specify the -dfha parameter
for the HDLM command's online operation.
#
The status changes to this status when using HAM (High Availability
Manager).
Correspondence Between Path Statuses Displayed by the OS and by HDLM
The following table lists the correspondence between the path statuses
displayed when commands such as the AIX lspath command are executed
and the path statuses displayed when the HDLM command's view operation is
executed.
Table 2-5 Correspondence Between Path Statuses Displayed by the OS and
by HDLM
Path status displayed by an AIX
command
Path status displayed by the HDLM
Enabled Either Online, Online(E), Online(S), or
Online(D)
Disabled Offline(C)
Failed Offline(E)
Status transitions of a path
The following figure shows the status transitions of a path.
HDLM Functions
2-21
Hitachi Dynamic Link Manager (for AIX) User Guide
