Message
ID
Message Text Explanation
correct them and then try
to collect error information
again. The DLMgetras will
ignore the specified file
and continue processing.
For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL10014-
W
You lack read permission for the specified
directory. Line = aa...aa, Value = bb...bb
Details
You lack read permission
for the specified directory
in the file for defining
information to be collected.
aa...aa: Line number of
the file for defining
information to be collected
(decimal number)
bb...bb: Indicated contents
in a line
Action
After the DLMgetras utility
for collecting HDLM error
information terminates,
check the contents of the
file for defining the
information to be collected.
This file is shown in the
message. If the contents of
the file are incorrect,
correct them and then try
to collect error information
again. The DLMgetras will
ignore the specified file
and continue processing.
For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL10015-
W
The file format is invalid. Value = aa...aa Details
The file format in the file
for defining information to
be collected is not a text
file.
aa...aa: Third parameter
Action
After the DLMgetras utility
for collecting HDLM error
8-92
