Message
ID
Message Text Explanation
information terminates,
check whether the file for
defining the information to
be collected is a text file.
The file is shown in the
message. For details on
the DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL10016-
W
The root directory has been specified in
the first parameter.
Details
A root "/" cannot be
specified in a directory to
which collected information
is output.
Action
Check the parameters of
the DLMgetras utility for
collecting HDLM error
information, and then re-
execute. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL10017-
W
You lack privileges for executing the
utility for collecting HDLM error
information.
Details
The DLMgetras utility for
collecting HDLM error
information must be
executed by a user with
root permissions.
Action
Re-execute as a user with
root permissions. For
details on the DLMgetras
utility, see
DLMgetras
Utility for Collecting HDLM
Error Information on page
7-5.
KAPL10020-
I
The file has been obtained successfully.
File = aa...aa, Collection time =
bb...bb(GMT:bb...bb)
Details
The file to be collected has
been obtained.
aa...aa: Collected file
name
bb...bb: Year/month/day
hour:minute:second
Action
None.
