Message
ID
Message Text Explanation
KAPL10021-
I
Processing terminated before completion
because a signal was received.
Details
The process has been
terminated by an operation
such as Ctrl+C.
Action
The utility for collecting
HDLM error information
terminated before
completion. If the directory
is unnecessary, delete
directory. For details on
the DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL10022-
I
The utility for collecting HDLM error
information completed normally.
Details
Error information has been
collected.
Action
None. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL10030-
I
A user terminated the utility for collecting
HDLM error information.
Details
Processing of the
DLMgetras utility for
collecting HDLM error
information has been
terminated because the
user replied to the
confirmation with an n
response.
Action
None. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL10031-
W
The entered value is invalid. Continue
operation ? [y/n]:
Details
A value other than y or n
has been entered for a
[y/n] request. Enter y or n.
Action
Enter y or n.
KAPL10032-
W
The entered value is invalid. The utility
for collecting HDLM error information
stops.
Details
Processing of the
DLMgetras utility for
8-94
Messages
Hitachi Dynamic Link Manager (for AIX) User Guide
