Message
ID
Message Text Explanation
collecting HDLM error
information will terminate
because an invalid
response was sent three
times in a row to a
request.
Action
Re-execute the DLMgetras
utility. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL10033-
W
The file does not exist. Filename = aa...aa Details
No file to collect
information exists.
aa...aa: File to collect
Action
None.
KAPL10034-
E
The file could not be copied. Filename =
aa...aa, Details = bb...bb
Details
Execution of the cp
command failed.
aa...aa: File name you
tried to copy
bb...bb : cp command
output message
Action
An error occurred while the
information collection file
was being copied. The
error might be a result of
an unstable user
environment. Check the
system configuration.
KAPL10035-
E
An attempt to archive the error
information failed. Details = aa...aa
Details
Execution of the tar
command failed.
aa...aa : tar command
output message
Action
See the details in the
message, and then remove
the cause of the error. For
information about the
error, collect the archive in
the output directory
specified at the time of
execution, and then
contact your HDLM vendor
