Message
ID
Message Text Explanation
or your maintenance
company if you have a
maintenance contract for
HDLM.
KAPL10036-
E
An attempt to compress the error
information failed. Details = aa...aa
Details
Execution of the compress
command failed.
aa...aa : compress
command output message
Action
See the details in the
message, and then remove
the cause of the error. For
information about the
error, collect the archive in
the output directory
specified at the time of
execution, and then
contact your HDLM vendor
or the maintenance
company if you have a
maintenance contract for
HDLM.
KAPL10049-
I
Error information collection command =
aa...aa, Return value = bb...bb, Execution
time = cc...cc
Details
A command was executed
to collect information
targeted for collection.
aa...aa: Executed
command
bb...bb: Return value of
the executed command
cc...cc: year (4 digits)/
month/date
hour:minute:second
Action
None.
KAPL10050-
I
The utility for collecting HDLM error
information started. Start time = aa...aa
(GMT aa...aa)
Details
The utility for collecting
HDLM error information
started.
aa...aa: year (4 digits)/
month/date
hour:minute:second
Action
None.
KAPL10521-
W
A parameter is invalid. (parameter =
aa...aa)
Details
aa...aa: invalid parameter
(character string)
