Message
ID
Message Text Explanation
Action
Execute help of the
dlmrmdev utility to check
the parameters that can be
specified, and then retry.
For details on the
dlmrmdev utility, see
dlmrmdev Utility for
Deleting HDLM Drivers on
page 7-30.
KAPL10523-
E
An attempt to unmount the file system
has failed. (file system = aa...aa)
Details
aa...aa: failed file system
(character string)
Action
Make sure of the status of
the failed file system and
then re-execute the
program. Unmount the
failed file system manually
and re-execute the
program.
For details on the
dlmrmdev utility, see
dlmrmdev Utility for
Deleting HDLM Drivers on
page 7-30.
KAPL10524-
E
An attempt to inactivate the volume
group has failed. (volume group =
aa...aa)
Details
An attempt to inactivate
the volume group has
failed.
aa...aa: failed volume
group (character string)
Action
Make sure of the status of
failed volume group and
then re-execute the
program. Inactivate the
failed volume group
manually and re-execute
the program.
For details on the
dlmrmdev utility, see
dlmrmdev Utility for
Deleting HDLM Drivers on
page 7-30.
KAPL10525-
E
An internal error occurred in the
dlmrmdev utility. (error code = aa...aa))
Execute the DLMgetras utility to collect
error information, and then contact your
vendor or maintenance company. Refer to
Details
In the dlmrmdev utility an
error not caused by a user
occurred.
Messages
