Message
ID
Message Text Explanation
To execute
dlmpostrestore utility,
enter y.
If you do not want to
execute dlmpostrestore
utility, enter n.
KAPL10556-
W
The entered value is invalid. Re-enter.
[y/n]:
Details
A value other than y or n
has been entered for a
[y/n] request.
Action
Enter either y or n.
KAPL10557-
I
The user stopped the operation. Details
The dlmpostrestore utility
has been terminated
because n was sent to a
request.
Action
None.
KAPL10558-
E
The entered value is invalid. The
operation will now stop.
Details
The dlmpostrestore utility
has been stopped because
an invalid response was
sent three times
consecutively to a request.
Action
To execute dlmpostrestore
utility again, enter either y
or n.
KAPL10559-
E
An internal error occurred in the
dlmpostrestore utility. Error Code =
aa...aa, bb...bb
Details
A system-based error, not
caused by the user,
occurred during
dlmpostrestore utility
processing.
aa...aa: Error number
(decimal number)
bb...bb: Return code
(decimal number)
Action
If the error code is 3 or 1:
Stop all of the
processes and services
that access the HDLM
management-target
device, and then
restart the
8-100
