Message
ID
Message Text Explanation
dlmpostrestore
utility.
Any other error code:
Contact your HDLM
vendor or the
maintenance
company, if you have
an HDLM maintenance
contract.
KAPL10560-
E
The system environment is invalid. Error
Code = aa...aa
Details
The system environment is
not valid as an
environment for executing
the dlmpostrestore
utility.
aa...aa: Error number
(decimal number)
Action
Contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM.
KAPL10561-
I
A user operation ended dlmpostrestore
utility.
Details
The dlmpstrestore
process has been
terminated by an operation
such as Ctrl+C.
Action
None.
KAPL10571-
I
The dlmchpdattr utility completed
successfully.
Action
None.
KAPL10572-
W
No parameter has been specified. Action
With the -h parameter
specified, execute the
dlmchpdattr utility. Make
sure that the format of the
utility is correct, and then
re-execute it.
KAPL10573-
W
A parameter is invalid. parameter =
aa...aa
Details
An invalid parameter is
specified.
aa...aa: The specified
parameter
Action
With the -h parameter
specified, execute the
