Message
ID
Message Text Explanation
dlmchpdattr utility. Make
sure that the format of the
utility is correct, and then
re-execute it.
KAPL10574-
W
The specified parameters cannot be
specified at the same time. parameter =
aa...aa
Details
aa...aa: The specified
parameter
Action
With the -h parameter
specified, execute the
dlmchpdattr utility. Make
sure that the format of the
utility is correct, and then
re-execute it.
KAPL10575-
W
No parameter value has been specified. Action
With the -h parameter
specified, execute the
dlmchpdattr utility. Make
sure that the format of the
utility is correct, and then
re-execute it.
KAPL10576-
W
A parameter value is invalid. parameter
value = aa...aa
Details
An invalid parameter value
has been specified.
aa...aa: The specified
parameter value
Action
With the -h parameter
specified, execute the
dlmchpdattr utility. Make
sure that the format of the
utility is correct, and then
re-execute it.
KAPL10577-
W
An attribute is invalid. attribute = aa...aa Details
An invalid attribute has
been specified.
aa...aa: The specified
attribute
Action
With the -h parameter
specified, execute the
dlmchpdattr utility. Make
sure that the format of the
utility is correct, and then
re-execute it.
KAPL10578-
W
An attribute value is invalid. attribute
value = aa...aa
Details
An invalid attribute value is
specified.
