Message
ID
Message Text Explanation
aa...aa: The specified
attribute
Action
With the -h parameter
specified, execute the
dlmchpdattr utility. Make
sure that the format of the
utility is correct, and then
re-execute it.
KAPL10579-
I
The HDLM default values will be changed.
Is this OK? [y/n]:
Details
This message confirms
whether it is okay to
execute the dlmchpdattr
utility.
Action
With the -h parameter
specified, execute the
dlmchpdattr utility. Make
sure that the format of the
utility is correct, and then
re-execute it.
KAPL10580-
W
The entered value is invalid. Re-enter.
[y/n]:
Details
A value other than y or n
has been entered for a
[y/n] request.
Action
Enter either "y" or "n".
KAPL10581-
I
The user stopped the operation. Details
The dlmchpdattr utility
was terminated because
the response to a request
was "n".
Action
None.
KAPL10582-
E
The entered value is invalid. The
operation will now stop.
Details
The dlmchpdattr utility
has been stopped because
an invalid response was
sent three times
consecutively to a request.
Action
To execute dlmchpdattr
utility again, enter either
"y" or "n".
KAPL10583-
E
An internal error occurred in the
dlmchpdattr utility. Error Code =
aa...aa,bb...bb
Details
A system-based error, not
caused by the user,
