Message
ID
Message Text Explanation
occurred during
dlmchpdattr utility
processing.
aa...aa: Error number
(decimal number)
bb...bb: Return code
(decimal number)
Action
If the error code is 9,1:
Confirm that all of the
processes and services
that use HDLM
managed paths have
stopped, and then
restart them.
If the error code is 19,1:
Check for path errors.
If there is a path
error, restore the path
status and then retry.
Contact your HDLM
vendor or the
maintenance
company, if you have
an HDLM maintenance
contract.
Any other error code:
KAPL10584-
E
The system environment is invalid. Error
Code = aa...aa,bb...bb
Details
The system environment is
not valid as an
environment for executing
the dlmchpdattr utility.
aa...aa: Error number
(decimal number)
bb...bb: Return code
(decimal number)
Action
If the error code is 3,2 or
4,-1:
The dlmrmdev utility is
not in the default
location, or the user
does not have
execution permissions
for the dlmrmdev
utility. Check the
status of the dlmrmdev
utility.
