Message
ID
Message Text Explanation
None.
KAPL10587-
W
The specified ODM is not installed.
parameter value = aa...aa
Details
The specified ODM is not
installed.
aa...aa: Specified
parameter value
Action
Specify an ODM that has
been installed, and then
retry the operation.
KAPL10588-
W
A duplicate attribute has been specified.
attribute = aa...aa
Details
A duplicate attribute has
been specified.
aa...aa: Specified attribute
Action
Delete the duplicate
attribute, and then retry
the operation.
KAPL10641-
I
Reservation Key will now be cleared. Is
this OK? [y/n]:
Details
Enter y to clear and n to
not clear the Reservation
Key.
Action
Enter y or n.
KAPL10642-
I
Reservation Key of aa...aa was cleared. Details
The Reservation Key has
been cleared.
aa...aa: logical device file
name for the HDLM
management-target device
Action
None.
KAPL10643-
W
A necessary parameter is not specified. Details
A parameter is not
specified for the dlmpr
utility.
Action
Execute the dlmpr -h
utility to check the
parameter, and then retry
execution. For details on
the dlmpr utility, see
dlmpr
Utility for Clearing HDLM
Persistent Reservation on
page 7-26.
