Message
ID
Message Text Explanation
KAPL10644-
W
The specified parameters cannot be
specified at the same time. parameter =
aa...aa
Details
The specified parameters
cannot be specified for the
dlmpr utility at the same
time.
aa...aa: specified
parameter (character
string)
Action
Execute the dlmpr -h
utility to check the
parameter, and then retry
execution. For details on
the dlmpr utility, see
dlmpr
Utility for Clearing HDLM
Persistent Reservation on
page 7-26.
KAPL10645-
W
A parameter value is invalid. parameter =
aa...aa
Details
An invalid parameter value
has been specified for the
dlmpr utility.
aa...aa: specified
parameter (character
string)
Action
Specify the correct value
for the parameter, and
then retry. For details on
the dlmpr utility, see
dlmpr
Utility for Clearing HDLM
Persistent Reservation on
page 7-26.
KAPL10646-
W
A parameter is invalid. parameter =
aa...aa
Details
An invalid parameter has
been specified for the
dlmpr utility.
aa...aa: specified
parameter (character
string)
Action
Execute help of the dlmpr
utility to check the
parameters that can be
specified, and then retry.
For details on the dlmpr
utility, see
dlmpr Utility for
Clearing HDLM Persistent
Reservation on page 7-26.
