Message
ID
Message Text Explanation
KAPL10650-
I
aa...aa: NO RESERVATION Details
A LU has not been
reserved.
aa...aa: Hdisk name
Action
None.
KAPL10651-
I
The user terminated the operation. Details
The dlmpr utility has been
terminated because n was
sent to a request.
Action
None.
KAPL10652-
E
The entered value is invalid. The
operation stops.
Details
An invalid response was
sent three times
consecutively to a request.
Action
Re-execute the dlmpr
utility.
KAPL10653-
W
The entered value is invalid. Please re-
enter it [y/n]:
Details
A value other than y or n
has been entered for a
[y/n] request.
Action
Enter y or n.
KAPL10665-
I
The dlmpr utility completed. Details
The dlmpr utility
completed normally.
Action
None. For details on the
dlmpr utility, see dlmpr
Utility for Clearing HDLM
Persistent Reservation on
page 7-26.
KAPL10670-
I
aa...aa: The HDLM driver's hdisk, which is
the boot disk, was excluded from the hard
disks subject to the clear operation.
Details
aa...aa: Hdisk name
Action
If you want to clear the
Reservation Key of the
HDLM driver's hdisk, which
is t
he boot disk, specify and
execute the dlmpr utility to
