Message
ID
Message Text Explanation
clear the HDLM persistent
reservation.
KAPL10800-
I
The dlmodmset utility completed
normally.
Details
The dlmodmset utility
completed normally.
Action
None. For details on the
dlmodmset utility, see
dlmodmset Utility for
Setting the HDLM
Execution Environment
ODM on page 7-22.
KAPL10801-
W
No parameter has been specified.
operation = aa...aa
Details
No parameter has been
specified.
aa...aa: Specified
operation (character
string)
Action
Execute help of the
dlmodmset utility to check
the parameters that can be
specified, and then retry.
For details on the
dlmodmset utility, see
KAPL08001 to KAPL09000
on page 8-56.
KAPL10802-
W
A parameter is invalid. operation =
aa...aa, parameter = bb...bb
Details
The specified parameter is
invalid.
aa...aa: Specified
operation (character
string)
bb...bb: invalid parameter
(character string)
Action
Execute help of the
dlmodmset utility to check
the parameters that can be
specified, and then retry.
For details on the
dlmodmset utility, see
KAPL08001 to KAPL09000
on page 8-56.
KAPL10804-
E
An internal error occurred in the
dlmodmset utility. Error Code = aa...aa
Execute the DLMgetras utility to collect
error information, and then contact your
vendor or maintenance company. Refer to
Details
An error not caused by the
user has occurred in the
dlmodmset utility.
