Message ID Message Text Explanation
¢
Get SNMP Trap
Information
¢
Set SNMP Trap
Information
¢
Set LU Load Balance
¢
Get Path Status Log
Information
¢
Get Local Time
¢
Add Path Information
¢
Delete Path
Information
¢
Set Storage
Identification
Information
Action
None.
KAPL11902-I aa...aa has started. PathID = bb...bb Details
The operation has started
on the management-target
host.
aa...aa: Operation
(character string)
¢
Online
¢
Offline
bb...bb: The Path ID of the
target path (decimal
number)
Action
None.
KAPL11903-I aa...aa has completed normally. Details
The operation has
completed normally on the
host.
aa...aa: Any of the
following operations
(character string)
¢
Get Path Information
¢
Get Option
Information
¢
Set Option
Information
¢
Clear Data
¢
Get HDLM Driver
Status
¢
Get HDLM Manager
Status
Messages
8-113
