Message ID Message Text Explanation
¢
Add Path Information
¢
Delete Path
Information
¢
Set Storage
Identification
Information
bb...bb: Error status
returned from API
(character string)
Action
Execute the DLMgetras
utility for collecting HDLM
error information to collect
the error information, and
then contact your HDLM
vendor or maintenance
company if there is a
maintenance contract for
HDLM. For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL11905-
E
An unexpected error occurred. Details
An exception occurred
during processing on the
host.
Action
Execute the DLMgetras
utility for collecting HDLM
error information to collect
the error information, and
then contact your HDLM
vendor or maintenance
company if there is a
maintenance contract for
HDLM.For details on the
DLMgetras utility, see
DLMgetras Utility for
Collecting HDLM Error
Information on page 7-5.
KAPL11906-I GUI information - aa...aa Details
This information is
required for resolving
problems.
aa...aa: Trace information
Action
None.
KAPL11907-I XML reception - aa...aa Details
Messages
8-115
Hitachi Dynamic Link Manager (for AIX) User Guide
