Message ID Message Text Explanation
This information is
required for resolving
problems.
aa...aa: XML information
Action
None.
KAPL11908-I XML transmission - aa...aa Details
This information is
required for resolving
problems.
aa...aa: XML information
Action
None.
KAPL13001 to KAPL14000
Message ID Message Text Explanation
KAPL13001-I The dlmmigsts utility completed
successfully.
Action
None.
KAPL13002-
E
The dlmmigsts utility ended abnormally. Action
Refer to action of the
message outputted just
before this message.
KAPL13003-I The specified file already exists. Do you
want to overwrite it? [y/n]:
Action
To overwrite the specified
file, enter y. To stop
execution, enter n.
KAPL13004-
W
The entered value is invalid. Re-enter.
[y/n]:
Action
Enter either y or n.
KAPL13005-
E
The entered value is invalid. The
operation will now stop.
Action
To execute dlmmigsts
again, re-execute. For
details about the
dlmmigsts utility, see
dlmmigsts Utility for
Assisting HDLM Migration
on page 7-20.
KAPL13006-I The user stopped the operation. Action
To execute dlmmigsts
again, re-execute. For
details about the
dlmmigsts utility, see
dlmmigsts Utility for
8-116
Messages
Hitachi Dynamic Link Manager (for AIX) User Guide
