Message ID Message Text Explanation
dlmmigsts again, and then
re-execute.If parameter =
-set, specify dlnksetfile in
dlmmigsts again, and then
re-execute. For details
about the dlmmigsts
utility, see dlmmigsts
Utility for Assisting HDLM
Migration on page 7-20.
KAPL13011-
W
The number of parameters is insufficient. Action
Specify the -h option in
the HDLM migration
support utility, confirm the
option that should be
specified, and then re-
execute. For details about
the dlmmigsts utility, see
dlmmigsts Utility for
Assisting HDLM Migration
on page 7-20.
KAPL13012-
W
Too many parameters have been
specified.
Action
Specify the -h option in
the HDLM migration
support utility, confirm the
option that should be
specified, and then re-
execute. For details about
the dlmmigsts utility, see
dlmmigsts Utility for
Assisting HDLM Migration
on page 7-20.
KAPL13013-
E
The directory for storing the specified file
could not be created. Filename = aa...aa
Details
aa...aa: Filename
(character string)
Action
There is not enough
capacity to store the
specified file in the
directory. Make sure there
is enough capacity, and
then try again. For details
about the dlmmigsts
utility, see
dlmmigsts
Utility for Assisting HDLM
Migration on page 7-20.
KAPL13014-
E
An internal error occurred in the
dlmmigsts utility. Error Code = aa...aa
Execute the DLMgetras utility to collect
error information, and then contact your
vendor or maintenance company. Refer
to the HDLM User's Guide for instructions
how to execute the DLMgetras utility.
Details
aa...aa: Error Code
(decimal number)
Action
