Message ID Message Text Explanation
Contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM.
KAPL13015-
E
There is an invalid character in the file.
parameter = aa...aa, Filename = bb...bb
Details
aa...aa: Parameter
(character string)
bb...bb: Filename
(character string)
Action
If parameter = -odm,
execute dlmodmset one
after another, or specify
the modified odmsetfile
in dlmmigsts again, and
then re-execute. For
details about the
dlmmigsts utility, see
dlmmigsts Utility for
Assisting HDLM Migration
on page 7-20. For details
on the dlmodmset utility,
see
dlmodmset Utility for
Setting the HDLM
Execution Environment
ODM on page 7-22.
If parameter = -set,
execute dlnkmgr set one
after another, or specify
the modified dlnksetfile
in dlmmigsts again, and
then re-execute.
KAPL13016-
E
The backup operation cannot be
performed because DLManager.rte is not
installed.
Action
Execute the dlmmigsts
utility in an environment
where DLManager.rte is
installed.
KAPL13017-
E
The restoration operation cannot be
performed because DLManager.mpio.rte
is not installed.
Action
Install
DLManager.mpio.rte, and
then execute the
dlmmigsts utility again.
KAPL13018-
E
The backup operation cannot be
performed because there is no /usr/
DynamicLinkManager/config/dlmmgr.xml
file. Execute the DLMgetras utility to
collect error information, and then
contact your vendor or maintenance
company. Refer to the HDLM User's
Action
Contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM.
