Message ID Message Text Explanation
Guide for instructions how to execute the
DLMgetras utility.
KAPL13019-
E
The same file name was specified for
odmsetfile and dlnksetfile. Filename =
aa...aa, bb...bb
Details
aa...aa: odmsetfile
Filename
bb...bb: dlnksetfile
Filename
Action
Check file name, and then
try again.
KAPL13020-
E
The file odmsetfile was not restored. Action
Check file name, and then
try again.
KAPL13021-
E
The file dlnksetfile was not restored. Action
Check file name, and then
try again.
KAPL13101-I The dlmpreremove utility completed
successfully.
Action
None.
KAPL13102-I HDLM can now be removed. Action
None.
KAPL13103-I HDLM can be removed after rebooting
the host.
Action
None.
KAPL13104-I The settings will be changed so that the
HDLM driver is not configured on the
hdisk. Is this OK? [y/n]
Action
To execute dlmpreremove,
enter y.
If you do not want to
execute dlmpreremove,
enter n.
KAPL13105-
W
The entered value is invalid. Re-enter.
[y/n]:
Action
Enter either y or n.
KAPL13106-
E
The entered value is invalid. The
operation will now stop.
Details
The dlmpreremove utility
has been stopped because
an invalid response was
sent three times
consecutively to a request.
Action
To execute dlmpreremove
again, enter either y or n.
KAPL13107-I The user stopped the operation. Details
The dlmpreremove utility
has been terminated
because n was sent to a
request.
