Message ID Message Text Explanation
Action
None.
KAPL13108-
E
An internal error occurred in the
dlmpreremove utility. Error Code =
aa...aa, bb...bb Execute the DLMgetras
utility to collect error information, and
then contact your vendor or maintenance
company. Refer to the HDLM User's
Guide for instructions how to execute the
DLMgetras utility.
Details
A system-based error, not
caused by the user,
occurred during
dlmpreremove utility
processing.
aa...aa: The error number
which specifies the
performed processing
(decimal number)
bb...bb: Return value of
the executed processing
(decimal number)
Action
Contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM.
KAPL13109-
W
A parameter is invalid. parameter =
aa...aa
Details
An invalid parameter is
specified.
aa...aa: The specified
parameter (character
string)
Action
With the -h parameter
specified, execute the
HDLM pre-remove utility
(dlmpreremove). Make
sure that the parameters
that should be specified
are correct, and then re-
execute. For details about
the dlmpreremove utility,
see
dlmpreremove Utility
for Executed Before
Removing HDLM on page
7-29.
KAPL13110-
E
The dlmpreremove utility cannot be
executed because the HDLM driver is
running. Execute the dlmrmdev utility,
and then re-execute the dlmpreremove
utility.
Action
Execute the dlmrmdev
command, and then re-
execute the
dlmpreremove. For details
about the dlmrmdev utility,
see
dlmrmdev Utility for
Deleting HDLM Drivers on
page 7-30.For details
about the dlmpreremove
Messages
8-121
Hitachi Dynamic Link Manager (for AIX) User Guide
