Message ID Message Text Explanation
utility, see dlmpreremove
Utility for Executed Before
Removing HDLM on page
7-29.
KAPL13141-I The dlmpremkcd utility completed
successfully.
Details
The dlmpremkcd utility
completed successfully.
Action
None.
KAPL13142-
W
No parameters were specified. Details
No parameters were
specified.
Action
With the -h parameter
specified, execute the
dlmpremkcd utility. Make
sure that the format of the
utility is correct, and then
re-execute it.
KAPL13143-
W
A parameter is invalid. parameter =
aa...aa
Details
An invalid parameter is
specified.
aa...aa: The specified
parameter
Action
With the -h parameter
specified, execute the
dlmpremkcd utility. Make
sure that the format of the
utility is correct, and then
re-execute it.
KAPL13144-
W
The specified parameters cannot be
specified at the same time. parameter =
aa...aa
Details
The specified parameters
cannot be specified at the
same time.
aa...aa: The specified
parameter
Action
With the -h parameter
specified, execute the
dlmpremkcd utility. Make
sure that the format of the
utility is correct, and then
re-execute it.
KAPL13145-I The dlmpremkcd utility will be executed.
Is this OK? [y/n]:
Details
This message confirms
whether it is okay to
execute the dlmpremkcd
utility.
