Message ID Message Text Explanation
Action
To execute the
dlmpremkcd utility, enter
"y". If you do not want to
execute the dlmpremkcd
utility, enter "n".
KAPL13146-
W
The entered value is invalid. Re-enter.
[y/n]:
Details
A value other than y or n
has been entered for a
[y/n] request.
Action
Enter either "y" or "n".
KAPL13147-I The user stopped the operation. Details
The dlmpremkcd utility
was terminated because
the response to a request
was "n".
Action
None.
KAPL13148-
E
The entered value is invalid. The
operation will now stop.
Details
The dlmpremkcd utility has
been stopped because an
invalid response was sent
three times consecutively
to a request.
Action
To execute dlmpremkcd
utility again, enter either
"y" or "n".
KAPL13149-
E
An internal error occurred in the
dlmpremkcd utility. Error Code =
aa...aa,bb...bb
Details
A system-based error, not
caused by the user,
occurred during
dlmpremkcd utility
processing.
aa...aa: Error number
(decimal number)
bb...bb: Return code
(decimal number)
Action
Contact your HDLM vendor
or the maintenance
company, if you have an
HDLM maintenance
contract.
KAPL13150-
E
The system environment is invalid. Error
Code = aa...aa,bb...bb
Details
The system environment is
not valid as an
Messages
8-123
Hitachi Dynamic Link Manager (for AIX) User Guide
