Message ID Message Text Explanation
environment for executing
the dlmpremkcd utility.
aa...aa: Error number
(decimal number)
bb...bb: Return code
(decimal number)
Action
Contact your HDLM vendor
or the maintenance
company, if you have an
HDLM maintenance
contract.
KAPL13151-I Processing terminated before completion
because a signal was received.
Details
The dlmpremkcd process
has been terminated by an
operation such as Ctrl+C.
Action
None.
KAPL13157-I The dlmrmprshkey utility completed
successfully.
Details
The dlmrmprshkey utility
completed successfully.
Action
None.
KAPL13158-
W
No parameter has been specified. Details
No parameter has been
specified.
Action
With the -h parameter
specified, execute the
dlmrmprshkey utility. Make
sure that the format of the
utility is correct, and then
re-execute it.
KAPL13159-
W
A parameter is invalid. parameter =
aa...aa
Details
An invalid parameter is
specified.
aa...aa: The specified
parameter
Action
With the -h parameter
specified, execute the
dlmrmprshkey utility. Make
sure that the format of the
utility is correct, and then
re-execute it.
KAPL13160-
W
The specified parameters cannot be
specified at the same time. parameter =
aa...aa
Details
