Message ID Message Text Explanation
The specified parameters
cannot be specified at the
same time.
aa...aa: The specified
parameter
Action
With the -h parameter
specified, execute the
dlmrmprshkey utility. Make
sure that the format of the
utility is correct, and then
re-execute it.
KAPL13161-
W
No parameter value has been specified. Details
No parameter value has
been specified.
Action
With the -h parameter
specified, execute the
dlmrmprshkey utility. Make
sure that the format of the
utility is correct, and then
re-execute it.
KAPL13162-
W
A parameter value is invalid. parameter
value = aa...aa
Details
An invalid parameter value
has been specified.
aa...aa: The specified
parameter value
Action
With the -h parameter
specified, execute the
dlmrmprshkey utility. Make
sure that the format of the
utility is correct, and then
re-execute it.
KAPL13163-I The dlmrmprshkey utility will now be
executed. Is this OK? [y/n]:
Details
This message confirms
whether it is okay to
execute the dlmrmprshkey
utility.
Action
To execute the
dlmrmprshkey utility, enter
"y". If you do not want to
execute the dlmrmprshkey
utility, enter "n".
KAPL13164-
W
The entered value is invalid. Re-enter.
[y/n]:
Details
A value other than y or n
has been entered for a
[y/n] request.
