Message ID Message Text Explanation
Action
Enter either "y" or "n".
KAPL13165-I The user stopped the operation. Details
The dlmrmprshkey utility
was terminated because
the response to a request
was "n".
Action
None.
KAPL13166-
E
The entered value is invalid. The
operation will now stop.
Details
The dlmrmprshkey utility
has been stopped because
an invalid response was
sent three times
consecutively to a request.
Action
To execute dlmrmprshkey
utility again, enter either
"y" or "n".
KAPL13167-
E
An internal error occurred in the
dlmrmprshkey utility. Error Code =
aa...aa,bb...bb
Details
A system-based error, not
caused by the user,
occurred during
dlmrmprshkey utility
processing.
aa...aa: Error number
(decimal number)
bb...bb: Return code
(decimal number)
Action
When the error code is
21,N, 24,N, 26,N, or 28,N:
Check for path errors. If
there is a path error,
recover the path from the
error, and then retry the
operation. When the error
code is 30,N; The target
device might not be using
persistent reservations
(shared-host
methodology). Use the
dlmpr utility to check
whether the target device
is using persistent
reservations (shared-host
methodology). All other
error codes: Contact your
HDLM vendor or, if you
have an HDLM
