Message ID Message Text Explanation
maintenance contract, the
maintenance company.
KAPL13168-
E
The system environment is invalid. Error
Code = aa...aa,bb...bb
Details
The system environment is
not valid as an
environment for executing
the dlmrmprshkey utility.
aa...aa: Error number
(decimal number)
bb...bb: Return code
(decimal number)
Action
Contact your HDLM vendor
or the maintenance
company, if you have an
HDLM maintenance
contract.
KAPL13169-
W
The specified device is not targeted for
processing. device name = aa...aa
Details
A device not targeted for
processing was specified.
aa...aa: Specified device
name
Action
None.
KAPL13170-I Processing terminated before completion
because a signal was received.
Details
The dlmrmprshkey process
has been terminated by an
operation such as Ctrl+C.
Action
None.
KAPL13171-I If you execute the dlmrmprshkey utility
and the server on which the specified
key value has been registered attempts
to access an LU, the attempt might fail
with an error.
Details
This message is a warning
to users before they
execute the dlmrmprshkey
utility.
Action
None.
KAPL13601-
W
The audit log configuration file does not
exist. Restart the HDLM Manager, and
execute the "dlnkmgr view -sys -audlog"
command and check the setting.
Details
The audit log configuration
file does not exist.
Action
Restart the HDLM
manager, execute the
"dlnkmgr view -sys -
audlog" command, and
then specify any desired
Messages
8-127
Hitachi Dynamic Link Manager (for AIX) User Guide
