Message ID Message Text Explanation
settings by using the
"dlnkmgr set -audlog"
command or the "dlnkmgr
set -audfac" command
as necessary.
KAPL13602-
W
The audit log configuration file cannot be
opened. Execute the "dlnkmgr view -sys
-audlog" command and check whether a
normal result is displayed.
Details
The audit log configuration
file cannot be opened.
Action
If the "dlnkmgr view -sys
-audlog" command does
not display a normal
result, contact your HDLM
vendor or maintenance
company if there is a
maintenance contract for
HDLM.
KAPL13603-
W
The audit log configuration file is invalid.
Restart the HDLM Manager, and execute
the "dlnkmgr view -sys -audlog"
command and check the setting.
Details
The audit log configuration
file is invalid.
Action
Restart the HDLM
Manager, and execute the
"dlnkmgr view -sys -
audlog" command, and
then specify the desired
setting by using the
"dlnkmgr set -audlog" or
the "dlnkmgr set -
audfac" command as
necessary.
KAPL13604-
W
An error occurred during processing to
read the audit log configuration file.
Details
An internal error occurred
during processing to read
the audit log configuration
file.
Action
Contact your HDLM vendor
or the maintenance
company if there is a
maintenance contract for
HDLM.
KAPL13605-
W
An error occurred during processing to
output the audit log configuration file.
Details
An internal parameter
error occurred during
output of the audit log
data.
Action
Contact your HDLM vendor
or the maintenance
