Message ID Message Text Explanation
KAPL15094-
E
An attempt to clear the server from the
PR_shared reservation for the target
device has failed. Command Line =
aa...aa
Details
aa...aa: Command that the
user executed
KAPL15101-I Clear operation was completed
successfully. Command Line = aa...aa
Details
aa...aa: Command that the
user executed
KAPL15102-
E
Clear operation has failed. Command
Line = aa...aa
Details
aa...aa: Command that the
user executed
KAPL15103-I aa...aa path(s) were successfully placed
bb...bb. cc...cc path(s) were not.
Command Line = bb...bb
Details
aa...aa: Number of paths
where online/offline is
successful
bb...bb: Online,
Online(S), Online(D) or
Offline(c)
cc...cc: Number of paths
where online/offline is
unsuccessful
KAPL15104-
W
aa...aa path(s) were failed to place
bb...bb. Command Line = cc...cc
Details
aa...aa: Number of paths
that failed to be placed
online or offline
bb...bb: Online or
Offline(c)
cc...cc: Command that the
user executed
KAPL15105-I Setting up the operating environment
succeeded. Command Line = aa...aa
Details
aa...aa: Command that the
user executed
KAPL15106-
E
Setting up the operating environment
failed. Command Line = aa...aa
Details
aa...aa: Command that the
user executed
KAPL15107-I Program information was successfully
displayed. Command Line = aa...aa
Details
aa...aa: Command that the
user executed
KAPL15108-
E
An attempt to display program
information has failed. Command Line =
aa...aa
Details
aa...aa: Command that the
user executed
KAPL15109-I Information about HDLM-management
targets was successfully displayed.
Command Line = aa...aa
Details
aa...aa: Command that the
user executed
