Message ID Message Text Explanation
KAPL15110-
E
An attempt to display information about
HDLM-management targets has failed.
Command Line = aa...aa
Details
aa...aa: Command that the
user executed
KAPL15111-
W
The HDLM command was started or
stopped by the user who does not have
the authority. Command Line = aa...aa
Details
aa...aa: Command that the
user executed
KAPL15116-I bb...bb path(s) were successfully placed
aa...aa. dd...dd path(s) were successfully
placed cc...cc. ee...ee path(s) were not.
Command Line = online
Details
aa...aa: Online or
Online(S)
bb...bb: The number of
paths which changed to
the Online or Online(S)
status
cc...cc: Online(S),
Online(D) or Online(S)/
Online(D)
dd...dd: The number of
paths which changed to
the Online(S) or
Online(D) status
ee...ee: The number of
paths which failed to
change to either the
Online, Online(S) or
Online(D) status
KAPL15117-I Addition of path(s) succeeded. Command
Line = aa...aa
Details
aa...aa: Command that the
user executed
KAPL15118-
W
Addition of path(s) failed. Command Line
= aa...aa
Details
aa...aa: Command that the
user executed
KAPL15119-I Deletion of path(s) succeeded. Command
Line = aa...aa
Details
aa...aa: Command that the
user executed
KAPL15120-
W
Deletion of path(s) failed. Command Line
= aa...aa
Details
aa...aa: Command that the
user executed
KAPL15401-I HDLM Manager successfully started.
KAPL15402-
E
Could not start the HDLM manager.
KAPL15403-I HDLM Manager successfully stopped.
KAPL15404-
W
The HDLM Manager was executed by the
user who does not have the authority.
8-132
Messages
Hitachi Dynamic Link Manager (for AIX) User Guide
