Message ID Explanation
1017 Details
The target path(s) are already Offline(C).
Action
Update the host information, and then check the path
status.
1019 Details
An error occurred during HDLM internal processing.
Action
Execute the DLMgetras utility for collecting HDLM error
information, and then contact your HDLM vendor or the
maintenance company if you have a maintenance contract
for HDLM. For details on the DLMgetras utility, see
DLMgetras Utility for Collecting HDLM Error Information on
page 7-5.
1020 Details
An unexpected error occurred during HDLM internal
processing.
Action
Execute the DLMgetras utility for collecting HDLM error
information, and then contact your HDLM vendor or the
maintenance company if you have a maintenance contract
for HDLM. For details on the DLMgetras utility, see
DLMgetras Utility for Collecting HDLM Error Information on
page 7-5.
1025 Details
A parameter value is invalid.
Action
Refresh the host information, and then perform the
operation again. If the same error occurs again, execute the
DLMgetras utility for collecting HDLM error information, and
then contact your HDLM vendor or maintenance company if
you have a maintenance contract for HDLM. For details on
the DLMgetras utility, see
DLMgetras Utility for Collecting
HDLM Error Information on page 7-5.
1026 Details
The acquisition of path information has been aborted,
because the path configuration was changed while the
system was attempting to acquire the path information.
Action
Refresh the host information, check the path status, and
then perform the operation again.
1027 Details
The error monitoring interval and the number of times that
the error needs to occur are conflicting with the automatic
failback-checking interval.
Action
8-134
Messages
Hitachi Dynamic Link Manager (for AIX) User Guide
