Message ID Explanation
DLMgetras utility for collecting HDLM error information, and
then contact your HDLM vendor or maintenance company if
you have a maintenance contract for HDLM. For details on
the DLMgetras utility, see DLMgetras Utility for Collecting
HDLM Error Information on page 7-5.
1041 Details
An attempt to communicate with the HDLM manager has
failed.
Action
Check whether the HDLM manager is running on the host. If
it is not running, start the HDLM manager.
1042 Details
Information about the path configuration on the specified LU
does not match the path configuration information held by
HDLM.
Action
Refresh the host information, check the path status, and
then perform the operation again.
1045 Details
A parameter is invalid.
Action
Refresh the host information, and then perform the
operation again. If the same error occurs even again,
execute the DLMgetras utility for collecting HDLM error
information, and then contact your HDLM vendor or
maintenance company if you have a maintenance contract
for HDLM. For details on the DLMgetras utility, see
DLMgetras Utility for Collecting HDLM Error Information on
page 7-5.
1046 Details
A parameter is invalid.
Action
Refresh the host information, and then perform the
operation again. If the same error occurs again, execute the
DLMgetras utility for collecting HDLM error information, and
then contact your HDLM vendor or maintenance company if
you have a maintenance contract for HDLM. For details on
the DLMgetras utility, see
DLMgetras Utility for Collecting
HDLM Error Information on page 7-5.
