• Eliminating the rc.shutdown file
HDLM version 5.8.1 or earlier provided an rc.shutdown file in order to
avoid having physical volumes already defined when a host is started.
Because this situation does not occur in HDLM version 5.9 or later, the
rc.shutdown file is no longer provided. For this reason, the manual has
been changed as follows:
¢
The portion of the procedure related to the rc.shutdown file has been
deleted from the explanation of removing HDLM.
¢
The rc.shutdown file has been deleted from the files collected by the
DLMgetras utility for collecting HDLM error information.
• The content displayed for HDevName in the HDLM view command
operation has been changed from the HDLM device (dlmfdrvn) to hdisk.
Accompanying this change, Device for displaying hdisk name when view
-lu or view -drv is executed in HDLM version 5.8.1 or earlier has been
removed.
• Because dlmfdrv was deleted, the following HDLM utilities are no longer
provided and the descriptions related to them have been deleted from the
manual:
¢
Utilities for operating HDLM volume groups
HDLM version 5.9 or later uses standard AIX commands that
correspond to the commands for utilities for operating HDLM volume
groups. The following table lists the correspondence between the
commands for the utilities for operating HDLM volume groups and the
standard AIX commands.
Table B-1 Commands of the utilities for operating HDLM volume
groups, and corresponding AIX commands
Commands of the utilities for
operating HDLM volume groups
Corresponding AIX commands
dlmchvg chvg
dlmexportvg exportvg
dlmextendvg extendvg
dlmimportvg importvg
dlmlistvgbackup listvgbackup
dlmlsvg lsvg
dlmmirrorvg mirrorvg
dlmmkvg mkvg
dlmrecreatevg recreatevg
dlmreducevg reducevg
dlmreorgvg reorgvg
dlmrestorevgfiles restorevgfiles
Differences Between HDLM Version 5.9 or Later and Version 5.8.1 or Earlier
B-3
Hitachi Dynamic Link Manager (for AIX) User Guide
