Error information is filtered according to the error level, and then collected.
In syslog, the HDLM messages on or above the level set by the user
configured in /etc/syslog.conf are collected. It is recommended that you
set the Information to be output at the info level or higher.
The error information in error logs and trace files are collected based on a
user-defined collection level. The collection levels are as follows:
Collection levels for error logs
¢
Collects no error information.
¢
Collects error information at the Error level and higher.
¢
Collects error information at the Warning level and higher.
¢
Collects error information at the Information level and higher.
¢
Collects error information at the Information level and higher
(including maintenance information).
Collection levels for log information in trace files:
¢
Outputs no trace information
¢
Outputs error information only
¢
Outputs trace information on program operation summaries
¢
Outputs trace information on program operation details
¢
Outputs all trace information
For details on how to set the collection level, see Setting Up the HDLM
Functions on page 3-78.
Collecting error information using the utility for collecting HDLM
error information (DLMgetras)
HDLM has a utility for collecting HDLM error information (DLMgetras).
By executing this utility, you can simultaneously collect all the information
required for analyzing errors: information such as error logs, integrated trace
files, trace files, definition files, core files, system crash dump files, and
libraries. You can use the collected information when you contact your HDLM
vendor or maintenance company (if there is a maintenance contract for
HDLM).
For details on the DLMgetras utility, see
DLMgetras Utility for Collecting HDLM
Error Information on page 7-5.
Collecting installation error information using the utility for
collecting HDLM installation error information (dlmgetrasinst)
HDLM has a utility for collecting HDLM installation error information
(dlmgetrasinst).
