By executing the dlmgetrasinst utility, you can collect system information
and log files needed to analyze errors that occurred during installation. You
can use the collected information when you contact your HDLM vendor or
maintenance company (if there is a maintenance contract for HDLM).
For details on the dlmgetrasinst utility, see DLMgetras Utility for Collecting
HDLM Error Information on page 7-5.
Collecting Audit Log Data
HDLM and other Hitachi storage-related products provide an audit log
function so that compliance with regulations, security evaluation standards,
and industry-specific standards can be shown to auditors and evaluators. The
following table describes the categories of audit log data that Hitachi storage-
related products can collect.
Table 2-9 Categories of Audit Log Data that Can Be Collected
Category Explanation
StartStop
An event indicating the startup or termination of
hardware or software, including:
• OS startup and termination
• Startup and termination of hardware components
(including micro-program)
• Startup and termination of software running on
storage systems, software running on SVPs (service
processors), and Hitachi Command Suite products
Failure
An abnormal hardware or software event, including:
• Hardware errors
• Software errors (such as memory errors)
LinkStatus
An event indicating the linkage status between devices:
• Link up or link down
ExternalService
An event indicating the result of communication between
a Hitachi storage-related product and an external service,
including:
• Communication with a RADIUS server, LDAP server,
NTP server, or DNS server
• Communication with the management server (SNMP)
Authentication
An event indicating that a connection or authentication
attempt made by a device, administrator, or end-user has
succeeded or failed, including:
• FC login
• Device authentication (FC-SP authentication, iSCSI
login authentication, or SSL server/client
authentication)
• Administrator or end-user authentication
HDLM Functions
2-35
Hitachi Dynamic Link Manager (for AIX) User Guide
