Categories and Audit Events that HDLM Can Output to the Audit Log
The following table lists and explains the categories and audit events that
HDLM can output to the audit log. The severity is also indicated for each audit
event.
Table 2-10 Categories and Audit Events that Can Be Output to the Audit
Log
Category Explanation Audit event
Severit
y
#1
Message ID
StartStop
Startup and
termination
of the
software
Startup of the HDLM
manager was
successful.
6 KAPL15401-I
Startup of the HDLM
manager failed.
3 KAPL15402-E
The HDLM manager
stopped.
6 KAPL15403-I
Startup of the
DLMgetras utility
6 KAPL15060-I
Termination of the
DLMgetras utility
#2
6 KAPL15061-I
Startup of the
dlmgetrasinst utility
6 KAPL15084-I
Termination of the
dlmgetrasinst
utility
#3
6 KAPL15085-I
Authentication
Administrator
or end-user
authenticatio
n
Permission has not
been granted to
execute the HDLM
command.
4 KAPL15111-W
Permission has not
been granted to
execute HDLM
utilities.
4 KAPL15010-W
Permission has not
been granted to start
or stop the HDLM
manager.
4 KAPL15404-W
ConfigurationAcces
s
Viewing or
updating
configuration
information
Processing of the
dlmpremkcd -c
command was
successful.
6 KAPL15088-I
Processing of the
dlmpremkcd -c
command failed.
3 KAPL15089-E
HDLM Functions
2-37
Hitachi Dynamic Link Manager (for AIX) User Guide
