Category Explanation Audit event
Severit
y
#1
Message ID
An attempt to display
HDLM management-
target information
failed.
3 KAPL15110-E
Processing of the
dlmpr -k command
was successful.
6 KAPL15001-I
Processing of the
dlmpr -k command
failed.
3 KAPL15002-E
Processing of the
dlmpr -c command
was successful.
6 KAPL15008-I
Processing of the
dlmpr -c command
failed.
3 KAPL15009-E
Processing of the
dlmodmset -o
command was
successful.
6 KAPL15005-I
Processing of the
dlmchpdattr -o
command was
successful.
6 KAPL15080-I
Processing of the
dlmchpdattr -o
command failed.
3 KAPL15081-E
Processing of the
dlmchpdattr -a
command was
successful.
6 KAPL15082-I
Processing of the
dlmchpdattr -a
command failed.
3 KAPL15083-E
The status of a path
was successfully
changed to Online.
6 KAPL15116-I
A path was
successfully added.
6 KAPL15117-I
Path addition failed. 4 KAPL15118-W
A path was
successfully deleted.
6 KAPL15119-I
Path deletion failed. 4 KAPL15120-W
#1
