program-name
¢
[process-ID]
¢
message-section
The following shows the format of message-section and explains its contents.
The format of message-section:
common-identifier,common-specification-revision-number,serial-
number,message-ID,date-and-time,entity-affected,location-
affected,audit-event-type,audit-event-result,subject-ID-for-audit-event-
result,hardware-identification-information,location-information,location-
identification-information,FQDN,redundancy-identification-
information,agent-information,host-sending-request,port-number-
sending-request,host-receiving-request,port-number-receiving-
request,common-operation-ID,log-type-information,application-
identification-information,reserved-area,message-text
Up to 950 bytes of text can be displayed for each message-section.
Table 2-12 Items Output in the Message Section
Item
#
Explanation
Common identifier Fixed to CELFSS
Common specification
revision number
Fixed to 1.1
Serial number Serial number of the audit log message
Message ID Message ID in KAPL15nnn-l format
Date and time The date and time when the message was output. This item is
output in the following format:
yyyy-mm-ddThh:mm:ss.s time-zone
Entity affected Component or process name
Location affected Host name
Audit event type Event type
Audit event result Event result
Subject ID for audit
event result
Depending on the event, an account ID, process ID, or IP
address is output.
Hardware identification
information
Hardware model name or serial number
Location information Hardware component identification information
Location identification
information
Location identification information
FQDN Fully qualified domain name
2-42
HDLM Functions
