Item
#
Explanation
Redundancy
identification
information
Redundancy identification information
Agent information Agent information
Host sending request Name of the host sending a request
Port number sending
request
Number of the port sending a request
Host receiving request Name of the host receiving a request
Port number receiving
request
Number of the port receiving a request
Common operation ID Operation serial number in the program
Log type information Fixed to BasicLog
Application identification
information
Program identification information
Reserved area This field is reserved. No data is output here.
Message text Data related to the audit event is output.
#: The output of this item depends on the audit event.
Example of the message section for the audit event
An attempt to display
HDLM management-target information was successful:
CELFSS,1.1,0,KAPL15109-I,
2008-04-09T10:18:40.6+09:00,HDLMCommand,hostname=moon,Configur
ationAccess,Success,uid=root,,,,,,,,,,,,,,,"Information about
HDLM-management targets was successfully displayed. Command
Line = /usr/DynamicLinkManager/bin/dlnkmgr view -path "
Integrated HDLM management using Global Link Manager
By using Global Link Manager, you can perform integrated path management
on systems running multiple instances of HDLM.
For large-scale system configurations using many hosts running HDLM, the
operational load for managing paths on individual hosts increases with the
size of the configuration. By linking HDLM and Global Link Manager, you can
centrally manage path information for multiple instances of HDLM and reduce
operational load. In addition, you can switch the operational status of paths
to perform system-wide load balancing, and centrally manage the system by
collecting HDLM failure information in Global Link Manager.
Global Link Manager collects and centrally manages information about paths
from instances of HDLM installed on multiple hosts. Even if multiple users
manage these hosts, they can control and view this centralized information
from client computers.
