HDLM System Requirements
Check the following before installing HDLM.
For OS patches and software provided by OS vendors, download them from
the Web site of the appropriate OS vendor.
For the requirements for using HDLM in an HAM environment, see the release
notes of HDLM.
Host and OS Support for HDLM
You can install HDLM on hosts running the OSs in the following table.
Table 3-1 Applicable OSs for the Host
OS Kernel
AIX 5L V5.3
#1
For Technology Level 06:
Apply SP9 or later
For Technology Level 07:
Apply SP6 or later
For Technology Level 08:
Apply APAR IZ43371
For Technology Level 09:
Apply SP2 or later and APAR IZ42658
For Technology Level 10
Apply SP1 or later
Technology Level 11
#2
For Technology Level 12
Apply SP1 or later
AIX 5L V5.3 (Virtual I/O
Server)
#5
ioslevel 2.1.0.0 to 2.2.3.xx (where xx is a number)
AIX V6.1
#1, #3
If Technology Level is not installed:
Apply SP1 or later and APAR IZ11722
For Technology Level 01:
Apply APAR IZ42661
For Technology Level 02:
Apply SP2 or later and APAR IZ42662
For Technology Level 03
Apply SP1 or later
Technology Level 04
#4
For Technology Level 05
Apply SP1 or later
Technology Level 06
Technology Level 07
For Technology Level 08
Creating an HDLM Environment
3-3
Hitachi Dynamic Link Manager (for AIX) User Guide
