OS Kernel
Apply SP1 or later
For Technology Level 09
Apply SP1 or later
AIX V6.1 (Virtual I/O Server)
#3,
#5
ioslevel 2.1.0.01 to 2.2.3.xx (where xx is a number)
AIX V7.1
#1, #3
No Technology Level
Technology Level 01
For Technology Level 02
Apply SP1 or later
For Technology Level 03
Apply SP1 or later
AIX V7.1 (Virtual I/O Server)
#3,
#5
ioslevel 2.1.0.0 to 2.2.3.xx (where xx is a number)
#1
Every SP is applicable, unless otherwise specified.
#2
To set up a boot disk environment that uses Thunder 9500V series,
Hitachi AMS/WMS series, or Hitachi SMS series, use SP2 or a later service
pack.
#3
An environment in which the Secure by Default functionality is enabled
during installation of the OS is not supported.
#4
To set up a boot disk environment that uses a storage system of the
Thunder 9500V series, Hitachi AMS2000/AMS/WMS/SMS series, or
HUS100 series, apply SP2 or a later service pack.
#5
HDLM supports PowerVM Live Partition Mobility in an environment in
which a virtual SCSI device or virtual HBA is used as the HDLM device.
Prerequisite Programs for HDLM
Before you install HDLM, confirm that the required programs written below
have been installed. For details about HTC_ODM and XP_ODM, contact the
storage system vendor.
• VisualAge C++ Runtime 5.0.0.0 or later, IBM XL C/C++ V7 Runtime
7.0.0.0 to IBM XL C/C++ V8 Runtime 8.0.0.0 or 8.0.0.6 or later (8.0.0.1
to 8.0.0.5 are not supported), IBM XL C/C++ V9 Runtime 9.0.0.1 or later,
or IBM XL C/C++ V10 Runtime 10.0.0.1 or later, or IBM XL C/C++ V11
Runtime 11.1.0.1 or later, or IBM XL C/C++ V12 Runtime 12.1.0.0 or
later
