Table 3-2 HDLM-Related Programs Required When Handling Intermediate
Volumes Managed by Hitachi RapidXchange
OS Related Programs
AIX 5L V5.3 File Access Library and File Conversion Utility (FAL/FCU)
01-03-56/20 or later
File Access Library and File Conversion Utility (FAL/FCU)
01-04-64/21 or later
AIX V6.1 File Access Library and File Conversion Utility (FAL/FCU)
01-07-68/00 or later
AIX V7.1 File Access Library and File Conversion Utility (FAL/FCU)
01-05-66/25 or later
File Access Library and File Conversion Utility (FAL/FCU)
01-06-67/21 or later
For details about Hitachi RapidXchange, see the manual File Access Library &
File Conversion Utility for Solaris HP-UX AIX Windows Tru64 UNIX NCR SVR4
DYNIX/ptx Linux.
Cluster Software Supported by HDLM
The following table lists the related programs required when you combine
cluster configurations.
Table 3-3 HDLM-Related Programs When Combining Cluster
Configurations
OS Related Programs
AIX 5L V5.3 • PowerHA 6.1
• Oracle RAC 10g 10.1.0.5.0
If the HDLM device is specified for direct access:
ASM + raw devices
#1
• Oracle RAC 10g 10.2.0.2.0
If the HDLM device is specified for direct access:
ASM + raw devices
#1
, or raw devices
#1
• Oracle RAC 10g 10.2.0.3.0
If the HDLM device is specified for direct access:
ASM + raw devices
#1#2
• Oracle RAC 10g 10.2.0.4.0
If the HDLM device is specified for direct access:
ASM + raw devices
#1
• Oracle RAC 10g 10.2.0.5.0
If the HDLM device is specified for direct access:
ASM + raw devices
#1
