OS Related Programs
AIX V7.1 (Virtual I/O
Server)
• PowerHA 6.1
Client: No Technology Level, or Technology Level 01 or later
Server: ioslevel 2.1.0.0 to 2.2.3.xx (where xx is a number)
• PowerHA 7.1
Client: No Technology Level, or Technology Level 01 or later
Server: ioslevel 2.1.0.0 to 2.2.3.xx (where xx is a number)
• PowerHA 7.1.1
Client: Technology Level supported by PowerHA
Server: ioslevel 2.1.0.0 to 2.2.3.xx (where xx is a number)
• PowerHA 7.1.2
Client: Technology Level supported by PowerHA
Server: ioslevel 2.1.0.0 to 2.2.3.xx (where xx is a number)
• PowerHA 7.1.3
Client: Technology Level supported by PowerHA
Server: ioslevel 2.1.0.0 to 2.2.3.xx (where xx is a number)
#1
When using Technology Level 05, apply IY92037.
#2
If you have updated the host environment by, for example, applying
Oracle-specific patches, the Oracle I/O timeout threshold (MISSCOUNT)
might have been changed. Therefore, when you update an environment,
you need to review the MISSCOUNT value.
#3
Only the NSD (Network Shared Disk) configuration is supported. Set the
usePersistentReserve option to no in the GPFS cluster configuration
information.
#4
VxVM is not supported.
#5
Sometimes, if JFS2 is being used and a crash (halt -q) fails over a node,
the resource to be mounted on the failover-destination node is not
properly mounted. This problem occurs regardless of whether HDLM is
installed.
#6
Apply fix pack 3.3.0.3 or later.
#7
Only the NSD (Network Shared Disk) configuration is supported.
#8
