When the NPIV option is set to on, HBA adapter number and bus number
for PathName, which are output by HDLM command view operations, are
changed to adapter type and adapter number respectively.
The view operation parameters for which the above changes are to be
applied are as follows:
¢
-path parameter (displays path information)
¢
-lu parameter (displays LU information)
¢
-hba parameter (displays HBA port information)
For details on the view operations, see
view (Displays Information) on
page 6-34.
Notes on the License Key and License Key File
• A license key or license key file is required when performing any of the
following types of installation:
¢
Performing a new installation of HDLM.
¢
Migrating from HDLM version 5.8.1 or earlier to version 5.9 or later.
¢
Upgrading or re-installing HDLM after the valid license period has
expired.
• To update the HDLM license, specify the -lic parameter in the HDLM
command's set operation, and then execute this command. The license
key type determines the expiration date of the license. For details about
license key types and the set operation, see
set (Sets Up the Operating
Environment) on page 6-18.
Notes on Trace Files
In HDLM 5.6 or later, trace files for versions of HDLM earlier than 5.6 are
divided into integrated trace files and trace files. The logs for the HDLM
command are output to integrated trace files. Trace information for an HDLM
manager is output to trace files. The output destinations for the files are
changed as follows:
When you migrate from HDLM 04-00 or earlier
Trace files before the migration: /opt/hitachi/HNTRLib/spool/
hntrn.log (n indicates a file number)
Integrated trace files after the migration: /var/opt/hitachi/HNTRLib2/
spool/hntr2n.log (n indicates a file number)
Trace files after the migration: /var/DynamicLinkManager/log/
hdlmtrn.log (n indicates a file number)
When you migrate from HDLM 05-00 or later
Trace files before the migration: /var/opt/hitachi/HNTRLib2/spool/
hntr2n.log (n indicates a file number)
Integrated trace files after the migration: /var/opt/hitachi/HNTRLib2/
spool/hntr2n.log (n indicates a file number)
