Upgrade installation
¢
Re-installation
¢
Unattended installation
• Use SMIT or the installp command.
You can also copy the contents of the HDLM DVD-ROM to a desired
directory, and then perform installation from that directory.
Copy the following files from the installation DVD-ROM to the same
directory:
¢
DLManager.mpio.bff
¢
.toc
To use SMIT, in software-input-device/directory specify the directory in
which the contents of the DVD-ROM have been copied.
• Unattended installation
An unattended installation enables a user to install HDLM without entering
information. For details about how to perform an unattended installation
of HDLM, see
Performing an Unattended Installation of HDLM on page
3-69.
• Installation on alternate disks
To use the AIX nimadm command, see Using the nimadm command to
simultaneously upgrade HDLM and migrate the OS on page 3-57 in
Performing an Upgrade Installation or Re-installation of HDLM on page
3-38.
By using the alt_disk_copy or nim command of AIX, you can replicate
the running system (clone) on an alternate disk, and then perform an
upgrade installation or re-installation of HDLM in AIX on the alternate
disk. The hdisk where the replication is created is called an alternate disk.
• Installation in a multibos environment
By using the AIX multibos command, you can perform an upgrade
installation of HDLM when a standby BOS is created or on an already
created standby BOS.
In addition to installing HDLM on a typical host, you can install it in the
following environments:
• Boot disk
• You can install HDLM on a virtual I/O server.
A virtual I/O server is a system that enables multiple client logical
partitions to share one resource.
• PowerHA environments
PowerHA is IBM’s HA cluster software that runs on AIX.
When Performing a New Installation, Upgrade Installation, or Re-installation of
HDLM
Table 3-7 Combination of Available Installation Methods and Installation
Environments on page 3-20 lists the combinations of available installation
methods and installation environments.Table 3-8 Combination of Installation
