Methods that Are Available in an PowerHA Environment and the Supported
Installation Environments on page 3-20 lists the combinations of installation
methods that are available in an PowerHA environment versus the supported
installation environments.
Table 3-7 Combination of Available Installation Methods and Installation
Environments
Installation
method
Installation environment
Host Virtual I/O server
Local boot
disk
environment
Boot disk
environment
Local boot
disk
environment
Boot disk
environment
installux.sh or
installp
command
Yes Yes Yes Yes
SMIT Yes Yes Yes Yes
Unattended
installation
Yes Yes Yes Yes
Installation on
alternate disks
Yes
#1
Yes
#1
Yes
#1
Yes
#1
Installation in a
multibos
environment
Yes
#2
Yes
#2
Yes
#2
Yes
#2
Legend:
Yes: Can be executed
No: Cannot be executed
#1
Only upgrade installations and re-installations are supported.
#2
Only upgrade installations are supported.
Table 3-8 Combination of Installation Methods that Are Available in an
PowerHA Environment and the Supported Installation Environments
Installation
method
Installation environment
Host Virtual I/O server
Local boot
disk
environment
Boot disk
environment
Local boot
disk
environment
Boot disk
environment
installux.sh
#1
or
installp
command
Yes Yes Yes Yes
SMIT Yes Yes Yes Yes
3-20
Creating an HDLM Environment
Hitachi Dynamic Link Manager (for AIX) User Guide
