When Installing HDLM on Alternate Disks on page 3-52 in Performing an
Upgrade Installation or Re-installation of HDLM on page 3-38
To use SMIT, see the AIX documentation.
When Performing a Migration of HDLM
Table 3-9 Combination of Available Migration Methods and Migration
Environments on page 3-22 lists the combinations of available migration
methods and target environments.
Table 3-10 Combinations of Migration
Methods Available in an PowerHA Environment and the Migration
Environments on page 3-23 lists the combinations of migration methods
that are available in an PowerHA environment and the migration destinations.
Table 3-9 Combination of Available Migration Methods and Migration
Environments
Migration method
Migration environment
Host Virtual I/O server
Local boot disk
environment
Boot disk
environment
Local boot
disk
environment
Boot disk
environment
installux.sh
#
or
installp
command
Yes N/A Yes N/A
SMIT Yes N/A Yes N/A
Unattended
installation
No N/A No N/A
Installation on
alternate disks
No No No No
Installation in a
multibos
environment
No No No No
Legend:
Yes: Can be executed
No: Cannot be executed
N/A: Not applicable
#
Only new installations, upgrade installations, and re-installations are
supported.
